Sale: EASY ARC - Simplicity, precision, repeatability. All in one mobile cell.
Easy Arc is a mobile robotic welding cell designed for industrial environments and ready for immediate operation. Optimized for small and medium-sized production batches, it enables MIG/MAG welding in combination with a vertical rotary positioner and an OTC FD-BT6 robot.
The compact construction and mobile frame ensure fast integration into the production process, while the perforated welding table enables efficient, accurate, and repeatable workpiece preparation.
Key advantages of the cell:
- Easy programming via the teaching pendant,
- High repeatability and consistent weld quality,
- Mobility ensured by robust wheels for simple movement across the shop floor.
The advanced pulsed arc enables high-speed and root welding with minimal spatter, automatic current and wire-feed control, and stable arc penetration.
The result is a reliable, stable process and excellent weld quality.
Technical specifications:
Air-cooled Welding Power Source: Welbee P402
Controller: FD19 for simplified operation
Rotary Positioner P-150V:
- Max. load capacity: 150 kg
- Max. rotation speed: 23.8 min⁻¹
- Table diameter: 300 mm
- Distance between centers: 650 mm
Robot: OTC FD-BT6
- Number of axes: 7
- working range: R 1435 mm
- payload capacity: 6 kg
Welding torch: RT3500H, air-cooled
Optional Add-ons:
- SynchroFeed – low-spatter welding technology.
- Offline programming.
- WeldUniverse Pro – monitoring and analytics system for complete productivity oversight.
- Arc Sensor FD-ARS and/or Touch Sensor FD-WDS.
For more information, contact us at prodaja@varstroj.si or 02 578 88 20
